Mitsubishi Outlander seats, seat belts and Supplemental Restraint System component locations

This illustration provides a visual overview of the Mitsubishi Outlander seating system, seat belt components, head restraints, child restraint attachment points and Supplemental Restraint System equipment. Use the numbered references to identify the location of each safety-related feature within the passenger compartment.

  1. Front SRS airbags, installed to provide supplemental protection for the driver and front passenger.
  2. Front passenger airbag status light, which indicates the operating status of the front passenger airbag system.
  3. Occupant classification sensors (weight sensors), used by the vehicle to detect conditions at the front passenger seat.
  4. Seat belts for securing occupants in their seating positions.
  5. Head restraints for the applicable seating positions.
  6. Side Curtain SRS airbags, positioned along the sides of the passenger compartment.
  7. Child restraint anchor point for attaching a top tether strap.
  8. Third row seats located at the rear of the Mitsubishi Outlander passenger compartment.
  9. Driver and passenger SRS knee airbags.
  10. Front seats for the driver and front passenger.
  11. Front seat-mounted SRS center airbag.
  12. Seat belt pretensioner system.
  13. Front seat-mounted SRS side airbags.
  14. Second row seats.
  15. LATCH (Lower Anchors and Tethers for CHildren) system for compatible child restraints installed in the second row seats.
  16. Second-row outboard seat-mounted SRS side airbags.
